The Rud-O-Matic Tagline holds a clamshell bucket steady regardless of the boom angle while the bucket and its load is suspended in the air. Operation is completely automatic after installation. Bell Guide fairlead requires no sheaves, pins or lubrication.

The Rud-O-Matic Tagline operates on a coil spring system that maintains constant, positive tension on a clamshell bucket or other types of crane loads.  The unit mounts on a crane boom and consists essentially of a cable reel, cable wire, spring-loaded cylinders, and a bell fairlead.

The Rud-O-Matic is offered in Single Barrel Tagline, Double Barrel Tagline, Triple Barrel Tagline and Four Barrel Taglines. Additional available options are Single, Double, or Triple Combination Magnet Reel s, Four Collector Ring Magnet Reel for high volt-low amp applications and finally the Combination Hydraulic Hose Reel and Tagline.

 SPECIFICATIONS AND MANUFACTURER’S RECOMMENDATIONS

Rud-O-Matic Taglines are manufactured in multiple models to accommodate various size buckets and booms. Each model is engineered to have sufficient cable pullout with the required positive tension to provide full control of the bucket in operation. Tagline model specifications and manufacturer’s recommendations for different buckets and booms are given below.

SHEAR PIN BREAKING POINT. To prevent coil spring over-winding, shear pin in bearing is designed to break and release spring tension if cable reel exceeds maximum recommended number of turns. Consult proper columns in chart to determine maximum number of cable reel turns for tagline model before shear pin will break.

 SINGLE BARREL

  • 624  —  30 inch housing,  good for small truck cranes with a cable pullout from neutral of 45ft.
  • 630  —  38 inch housing,  good for 3/8 yard to 5/8 yard buckets and 30 feet of boom with a cable pullout from neutral of 60ft.
  • 636  —  46 inch housing,  good for a 3/4 yard bucket and 40-60 feet of boom with a cable pullout from neutral of 70 feet.
  • 648  —  60 inch housing,  good for a 1 yard to 11/2 yard bucket and 80 feet of boom with a cable pullout from neutral of 90ft.
  • 666  —  78 inch housing,  good for 1 yard to 11/2 yard buckets and deep digging with a cable pullout from neutral of 135 feet.

 DOUBLE BARREL

  • 1248  —  with a 20” reel, 60 inch housing,  good for 11/2 yard to 4 yard buckets and 80 ft boom with a cable pullout from neutral of 90ft.
  • 1248  —  with a 30” reel, 60 inch housing,  good for 11/2 yard to 2 yard buckets and 100 ft boom with a cable pullout from neutral of 125 feet.
  • 1266  —  with a 30” reel, 78 inch housing,  good for a 11/2 yard to 2 yard bucket and deep digging with a cable pullout from neutral of 200 feet.
  • 1266 * —  with a 40” reel, 78 inch housing,  good for a 11/2 yard to 2 yard bucket and deep digging with a cable pullout from neutral of 250 feet.

* Available with .437 coil spring wire for jobs requiring greater tension  good for a 2 yard to 5 yard bucket and deep digging with a cable pullout from neutral of 180 feet.



TRIPLE BARREL

  • 1848  —  with a 20” reel, 60 inch housing,  good for 4 yard to 8 yard buckets and 80 ft boom with a cable pullout from neutral of 90ft.
  • 1848  —  with a 30” reel, 60 inch housing,  good for 3 yard to 5 yard buckets and 100 ft boom with a cable pullout from neutral of 125 feet.
  • 1866  —  with a 30” reel, 78 inch housing,  good for a 3 yard to 5 yard bucket and digging approximately 100 ft below grade with a cable pullout from neutral of 200 feet.
  • 1866 * —  with a 40” reel, 78 inch housing,  good for a 4 yard to 5 yard bucket and digging approximately 100 ft below grade with a cable pullout from neutral of 250 feet.

* Available with .437 coil spring wire for jobs requiring greater tension  good for a 5 to 10 yard bucket and medium digging to approximately 60 ft below grade with a cable pullout from neutral of 180 feet.

 SPECIFICATIONS AND RECOMMENDATION FOR SINGLE BARREL CMR & SMR MODELS USED WITH HIGH VOLT-LOW AMP DC POWER

The Rudomatic Single Barrel CMR and Standard Magnet Reel are each manufactured in five basic models to accommodate different size magnets and loads. This chart provides data for a range of combination and is designed to serve as a guide in selecting the most suitable model.

FOR STANDARD MAGNET REELS on booms or overhead cranes, tagline cable pullout figures provide a close approximation for length of electric cable to be used. Diameter and weight of magnet have no bearing in determining length of electric cable for Standard Magnet Reel.

MAGNET to MAGNET REEL match up

  • 26” Magnet (900 lbs) with no. 10 electric cable  à  use model 624
  • 32” Magnet (1540 lbs) with no. 10 electric cable à use model 630
  • 37” Magnet (1600 lbs) with no. 8 electric cable à use model 636
  • 38” Magnet (2000 lbs) with no. 8 electric cable à use model 636
  • 45” Magnet (3100 lbs) with no. 8 electric cable à use model 648
  • 48” Magnet (3900 lbs) with no. 6 electric cable à use model 648 for 90ft pullout
  • 48” Magnet (3900 lbs) with no. 6 electric cable à use model 666 for 135ft pullout
  • 50” Magnet (2300 lbs) with no. 6 electric cable à use model 648 for 90ft pullout
  • 50” Magnet (2300 lbs) with no. 6 electric cable à use model 666 for 135ft pullout
  • 50” Magnet (4200 lbs) with no. 4 electric cable à use model 648 for 90ft pullout
 SPECIFICATIONS AND RECOMMENDATION FOR NON-SINGLE BARREL CMR & SMR MODELS USED WITH HIGH VOLT-LOW AMP DC POWER

The chart below provides data on a range of available models using high volt-low amp DC power. Models with 1200-numbers indicate double barrel magnet reels; models with 1800-numbers indicate triple barrel magnet reels. The same model number applies to either the Combination or Standard Magnet Reel. Specifications are the same, except for tagline cable pullout. The list is included to help our customers select other models that may also suit their needs.

MAGNET to MAGNET REEL match up

  • 58” Magnet (5800 lbs) with no. 4 electric cable à use model 1248
  • 58” Magnet (6800 lbs) with no. 4 electric cable à use model 1248
  • 70” Magnet (8400 lbs) with no. 2 electric cable à use model 1248 for 90ft pullout
  • 70” Magnet (8400 lbs) with no. 2 electric cable à use model 1266 for 200ft pullout
  • 70” Magnet (9500 lbs) with no. 2 electric cable à use model 1248 for 90ft pullout
  • 70” Magnet (9500 lbs) with no. 2 electric cable à use model 1266 for 200ft pullout
  • 71” Magnet (11,000 lbs) with no. 2 electric cable à use model 1848 for 125ft pullout
  • 71” Magnet (11,000 lbs) with no. 2 electric cable à use model 1266 for 200ft pullout
  • 75” Magnet (12,000 lbs) with no. 1 electric cable à use model 1848 for 125ft pullout
  • 75” Magnet (12,000 lbs) with no. 1 electric cable à use model 1266 for 200ft pullout
  • 76” Magnet (13,200 lbs) with no. 1 electric cable à use model 1848 for 125ft pullout
  • 76” Magnet (13,200 lbs) with no. 1 electric cable à use model 1266 for 200ft pullout
  • 79” Magnet (13,400 lbs) with no. 1 electric cable à use model 1848 for 125ft pullout
  • 79” Magnet (13,400 lbs) with no. 1 electric cable à use model 1866 for 200ft pullout
  • 80” Magnet (18,000 lbs) with no. 1 electric cable à use model 1848 for 125ft pullout
  • 80” Magnet (18,000 lbs) with no. 1 electric cable à use model 1866 for 200ft pullout
  • 88” Magnet (24,000 lbs) with no. 1/0 electric cable à use model 1848 for 125ft pullout
  • 88” Magnet (24,000 lbs) with no. 1/0 electric cable à use model 1866 for 200ft pullout
